Scanbox Watering Hole Targets Pakistani and Tibetan Government Website Visitors
Click here to download the complete analysis as a PDF.
This report outlines recent Scanbox campaigns targeting a Pakistani government department and the Central Tibetan Administration in early March 2019. Insikt Group researchers utilized data from the Recorded FutureⓇ Platform, Shodan, Farsight Security DNS, third-party network metadata, and common OSINT techniques.
This report will be of most interest to network defenders seeking to understand the threat posed by cyberespionage actors leveraging strategic web compromises to conduct network reconnaissance, in advance of a more concerted effort to gain access to their network.
In early March 2019, Recorded Future’s Insikt Group identified two separate Scanbox campaigns using strategic web compromises to target visitors to the website of Pakistan’s Directorate General of Immigration and Passports (DGIP) and a spoof of the official Central Tibetan Administration (CTA) website. It is likely that in both cases, the attackers intended to profile the devices of website visitors in order to conduct follow-on intrusions.
Insikt Group highlights this activity to enable the protection of targeted communities and to raise awareness of the risks posed by in-memory reconnaissance frameworks, such as Scanbox, used widely by Chinese state-sponsored threat actors, which employ features that enable keylogging and the deployment of additional malware on unsuspecting website visitors.
Analysis of the Tibetan Scanbox deployment highlights several associated domains and IPs revealing a wider campaign of targeting against Tibetan interests.
Scanbox has been used previously in the targeting of persecuted minority groups, such as the Uighurs and Tibetans in China.
First noted in early 2014, Scanbox has been used in several high-profile intrusions, including the Anthem breach and the Forbes watering hole attacks, and has been widely adopted by China-based threat actors, including Leviathan (APT40, Temp.Periscope), LuckyMouse (TG-3390, Emissary Panda, Bronze Union), APT10 (menuPass, Stone Panda), and APT3 (Pirpi, Gothic Panda).
Summary of Scanbox use since 2014. (Source: Recorded Future)
Pakistan DGIP Scanbox Instance
On March 4, 2019, Insikt Group identified that the online passport application tracking system on Pakistan’s DGIP website (tracking.dgip.gov[.]pk) was compromised by attackers who had deployed Scanbox code onto the page. Website visitors were redirected as a result of the strategic web compromise (SWC), also known as watering holes, to an attacker-controlled Scanbox server hosted on Netherlands IP 185.236.76[.]35, enabling the attackers to deploy Scanbox’s wide array of functionality.
Further details about this Scanbox deployment can be found in a recently published blog by Trustwave.
Scanbox-infected webportal for the tracking system on Pakistan’s DGIP.
Central Tibetan Administration Scanbox Instance
Insikt Group researchers were alerted to a new domain registration within the Recorded Future platform that triggered on a typosquatting rule for tibct[.]net. The domain was first registered on March 6, 2019.
New domain registration event noted in the Recorded Future portal and triggering of typosquat risk rule.
When analyzed, the site exhibited content similarities with the legitimate website of the CTA, as shown below:
Side-by-side comparison of spoof CTA website tibct[.]net (left), and the legitimate CTA website tibet[.]net (right).
Visitors likely intending to visit the official CTA website, tibet[.]net, were being duped into navigating to tibct[.]net, possibly via links in spearphish emails that were then subsequently redirected to the Scanbox C2 domain oppo[.]ml.
Pivoting from the spoofed domain, tibct[.]net, in WHOIS data revealed that the same email address was used by the attackers to register the domains tibct[.]org (registered March 5, 2019) and monlamlt[.]com (registered March 11, 2019), both of which appear to either host resources relating to Tibet or are typosquats of official CTA domains. Analysis of these domains in Farsight Security’s DNSDB reveal further closely associated infrastructure.
|tibct[.]net||139.59.90[.]169 (March 7 – 8, 2019), 103.255.179[.]142 (March 9, 2019)||Domain registered using address located in Guangdong, China; Typosquat of tibet[.]net|
|tibct[.]org||–||Typosquat of CTA site tibet[.]net|
|monlamlt[.]com||23.225.161[.]105||Typosquat of monlamit[.]com, a Tibetan IT resources and support site|
|mailshield[.]ga||23.225.161[.]105||Possible spoof of an AV product|
|photogram[.]ga||23.225.161[.]105||Possible image sharing spoof (e.g., Instagram)|
|mail.mailshield[.]ga||23.225.161[.]105||Possible spoof of an AV product|
These Scanbox intrusions, which were detected by Insikt Group within a few days of each other, show that the tool is still popular with attackers and is being used against organizations that are broadly aligned with the geopolitical interests of the Chinese state. Based on the identity of the two targeted organizations, as well as the well documented historic use of Scanbox by a variety of Chinese APTs, we assess with low confidence that these Scanbox deployments were likely conducted by Chinese state-sponsored threat actors.
Network Defense Recommendations
Recorded Future recommends organizations implement the following measures when defending against Scanbox targeting as documented in this research:
Configure your intrusion detection systems (IDS), intrusion prevention systems (IPS), or any network defense mechanisms in place to alert on — and upon review, consider blocking illicit connection attempts from — the external IP addresses and domains listed in Appendix A.
Implement the provided Snort rules in the threat hunting package attached in Appendix B into your IDS and IPS appliance and investigate any alerts generated for activity resembling the TTPs outlined in this report.
Conduct regular YARA scans across your enterprise for the Scanbox rules listed in the threat hunting package in Appendix B.
Recorded Future customers can be alerted to new samples matching the YARA rule currently deployed by Insikt Group researchers within the Recorded Future platform.
To view a full list of the associated indicators of compromise, download the appendix.
